PZKHCT Split Core Current Transformer 100A Coil Sensor

PZKHCT Split Core Current Transformer – 100A Coil Sensor for Energy Meters

The PZKHCT Split Base Current Transformer is a compact, fully enclosed coil sensor designed for accurate current measurement up to 100A. Engineered for energy meters operating on AC 220V or 380V power supplies, this mini split-core CT sensor offers outstanding mechanical durability, strong voltage isolation, and effortless clamp-on installation — no need to cut power or interrupt your circuit during setup.

Key Features

• Mini Split-Core Design: One of the smallest split-base current transformers of its class (100mA output), ideal for tight installations.
• Snap-Joint Structure: Clamps directly onto existing cables using nylon ties — no wire cutting or power shutdown required.
• 16mm Inner Hole Diameter: Accommodates a wide range of cable sizes with ease.
• High Accuracy: ≤0.5 grade accuracy ensures reliable current measurement for energy metering applications.
• Fully Enclosed Housing: Excellent mechanical properties, environmental resistance, and strong voltage isolation for safe, dependable operation.
• Wide Temperature Range: Operates from -40°C to +85°C, suitable for demanding environments.
• UL94-V0 Flame Resistance: Built to meet international flame-retardant standards.
• Built-In Input Coil: Lightweight and easy to install without specialized tools.

Technical Specifications

Important Installation Notes

1. Connect the CT primary in series with the test current loop; the secondary must operate in short-circuit state.
2. The secondary circuit must never be left open — do not install a fuse on this side.
3. Never open-circuit the secondary side. Always connect wiring to the secondary side first, then the primary. When removing, disconnect the primary side first, then the secondary.
4. Ensure wire diameter matches hole diameter; select a specification with an inner hole diameter larger than your wire diameter. Fully fasten the opening/closing surfaces until you hear a clear "click" — the latch must be completely locked.
5. This transformer measures alternating current only (50/60Hz).

What's in the Box

• 1 × PZKHCT Split Core Current Transformer

Made in Mainland China.
