PWM Regulator DC 5V-36V MOSFET Switch Drive Module 400W

PWM Regulator Control Panel — DC 5V–36V MOSFET Switch Drive Module

Take precise control of your DC-powered devices with this versatile PWM Regulator Control Panel. Designed for a wide voltage range of DC 5V to 36V, this MOSFET-based switch drive module is an ideal solution for controlling lamp brightness, motor speed, fan regulation, and other high-power DC loads — all from a compact, easy-to-install board.

Key Features

• Wide Voltage Range: Compatible with DC 5V to 36V input, making it suitable for a broad range of applications and power supplies.
• PWM Signal Compatible: Accepts external PWM signals (0–20 kHz) for smooth, precise duty-cycle control of connected devices.
• High-Power MOSFET Switch: Capable of handling up to 400W / 15A continuous (30A peak), giving you reliable performance for demanding loads.
• Compact Panel Design: Lightweight and space-efficient at approximately 34mm — fits neatly into project enclosures, control boxes, or DIY builds.
• Versatile Use Cases: Perfect for LED lamp brightness control, DC motor speed regulation, solenoid switching, and general-purpose power switching projects.
• Simple Integration: Screw-terminal connections and clear labeling make wiring fast and straightforward, even for hobbyists.

Specifications

• Input Voltage: DC 5V – 36V
• Max Continuous Current: 15A (30A peak)
• Max Power: 400W
• PWM Frequency: 0 – 20 kHz
• Switch Type: N-Channel MOSFET

What's in the Box

• 1 × PWM Regulator Control Panel (DC 5V–36V MOSFET Switch Drive Module)

For guidance on safe electrical practices and working with DC power electronics, visit the OSHA Electrical Safety Resource.

Frequently Asked Questions

Q: What does the PWM Regulator Control Panel DC 5V-36V MOSFET Switch Drive do?

A: This module acts as a high-power electronic switch and PWM controller. It allows you to regulate the power delivered to a DC load — such as LED lights, motors, or fans — by accepting a PWM control signal (0–20 kHz) and switching the MOSFET accordingly. You can smoothly adjust brightness, speed, or power output without wasting energy as heat.

Q: What devices can I control with this MOSFET switch drive module?

A: The module is suitable for controlling any resistive or inductive DC load within the rated voltage (5V–36V) and current (up to 15A continuous / 30A peak) range. Common applications include LED strip brightness control, DC motor speed control, cooling fans, water pumps, solenoid valves, and other high-power DC switching tasks in DIY electronics or automation projects.

Q: Is this module easy to install for hobbyists and makers?

A: Yes. The board features clearly labeled screw terminals for power input, load output, and PWM signal input, making wiring straightforward. It works right out of the box with any compatible DC power supply and a PWM signal source such as a microcontroller (e.g. Arduino) or a dedicated PWM generator. Always ensure your power supply and wiring are rated for the load current before connecting.
